    Brand Name : Osign
    Model Number : OCAV160
    Supply Ability : 500000 Rolls Per Week
    Price : Negotiable
    Delivery Time : 1-3 Days
    Payment Terms : T/T, money gram, western union, L/C, D/P
    • Product Details
    • Company Profile

    color? change film for car

    color? change film for car /matt black sticker with bubble free /auto stickers /carbon fiber tape /carbon fiber vinyl film/ 3D carbon film Top quality&economic type optional


    Advantages

    Osign brand Carbon Fiber Vinyl are flexible PVC films with perfect adhesive intended to cover all type of the surfaces, such as wall covering, furniture, fixture, ceiling, doors, elevators, exterior/interior applications.


    Osign brand Carbon Fiber Vinyl are durable, dimensionally stable, vinyl films that were specifically developed for interior/exterior decorations and refurbishment.


    Effective Performance Life

    The warranty for Osign brand Carbon Fiber Vinyl for interior/exterior decoration as stated here extend to automotive or personal vehicle applications . The warranty applies to films that are exposed interior/exterior at a vertical angle (defined as +/-10°). A significant decrease in durability may be experienced if films are exposed other than vertically. Such non-vertical application should be based on Osign tests results and approval to determine acceptability. Effective Performance Life of unprinted interior/exterior

    Osign brand Carbon Fiber Vinyl depends on application exposure zones as follows.


    Fabrication Cutting with Electronic Systems

    Osign Carbon Fiber Vinyl is normally applied in sheets directly from the roll. In case people want to cut or screen print that is possible but not the primary intention of the film. Knife adjustment may be required as the product construction may differ from comparable products. The minimum height for text is 10 mm.


    Physical and Chemical Properties

    Values given are typical and are not for use in specifications. If a custom specification is desired, a request should be submitted through your sales representative. The following data is given for unprinted film.

    Application Temperature

    We recommends applying Carbon Fiber Vinyl products at 15°C - 38°C.


    Physical Properties

    Property

    Metric Units

    Thickness (Film + Adhesive)

    0.170mm– 0.180 mm

    Elongation

    > 100 %

    Dimensional Stability (X-gash)

    > 0.3 mm max

    Abrasion Resistance

    Taber abrasion (0.5 kg load, CS-17)

    1000 cycles

    Surface will be damaged

    Impact Resistance

    (Gardner at 0°C), 2 lb X 5 inch at 4°C


    No effect

    Humidity Resistance at 40°C (95% RH X 7 days)

    No effect

    Water Resistance (40°C water X 7 days)

    No effect

    Stain Resistance 18 hours

    Milk, Coffee, Wine, Lemon juice, Tea, Vinegar, Soybean oil, Salt water (1%), Ammonium water, Soap water (1%), Synthetic detergent, Hydrochloric acid (10%), Sodium hydroxide (10%)


    No effect


    Adhesion (N/25 mm)

    Substrate

    Adhesion (No Primer)

    Adhesion (W/DP-900N)

    Lauan Veneer

    4.9

    34.3

    China Veneer

    4.9

    30.4

    Plaster Board

    -

    4.9*

    Asbestos Slate Board

    4.9

    34.3

    Melamine-baked Steel Sheet

    30.4

    52

    Phosphate-coated Steel Sheet

    24.5

    54

    PVC-coated Steel Sheet

    44.1

    44.1

    Aluminum

    27.1

    39

    Stainless Steel Sheet

    37.2

    42

    Acrylic Board

    38.2

    54.9

    Mortar

    3.9

    21.6


    Chemical Resistance

    Product applied to an aluminum panel, conditioned for 72 hours and then immersed in the chemical agents.


    Stain Resistance

    Carbon Fiber Vinyl product applied to an aluminum panel and placed in direct contact with the following substances at 20°C, 65%RH.


    Flammability

    Information about the new Carbon Fiber Vinyl approval numbers according to various test standards

    Approval Type, Number

    Product Type

    Test Substrate

    Classification

    Copy of

    Certificate

    IMO

    FW 646

    Non-flammable substrate

    Non-combustible

    GPRD

    SBI


    EN 13823:2002

    ST 553

    Non-flammable substrate

    B-s2,do

    GPRD

    DIN 4102-1

    Product Group 1-10

    (all DI-NOC films)

    Non-flammable substrate

    B1

    GPRD

    DIN 54837

    PS, WG

    Non-flammable substrate

    Non-combustible

    GPRD

    FAR-25.853

    WG 165

    Non-flammable substrate

    Non-combustible

    GPRD


    Cleaning/Maintenance

    For cleaning of applied Carbon Fiber Vinyl use a soft textile with detergent and water. For heavy dirt accumulation use detergent and water at 70°C - 80°C.


    Removal

    Carbon Fiber Vinyl are removable with a heat gun at 80°C – 100°C or the Bosch steam remover PTL1 can be used.


    Shelf Life, Storage, Shipping

    The fabricator may store unprinted film for a period of up to three years. Film and markings must be stored in a clean area, free from excessive moisture and direct sunlight, on at least a 3" core with the film facing outward, with ambient temperatures of 35°C or less.
